PREMABRAZE 616 (61.5AG/24CU/14.5IN)

Product Overview

Premabraze 616 is a high purity, low temperature silver braze alloy used mostly for brazing electronic vacuum tube systems or other vacuum grade systems where high vapor pressure elements can not be tolerated.
  • Brazed in vacuum without vaporization
  • Low temperature
  • Sluggish
  • High purity
Industry Applications:
Vacuum tube components
Talk to an Expert

Product Specifications

Name:PREMABRAZE 616 (61.5AG/24CU/14.5IN)
Nominal Composition:Silver 61.50, Copper 24.00, Indium 14.50,
Ag
61.50
Cu
24.00
In
14.50
Liquidus:1305 °F, 705 °C
Solidus:1155 °F, 625 °C
AWS:AWS: BVAg-29 Grade 1, 2
